- new type:
- 61952ma/c3vl0241
- old type:
- 61952ma/c3vl0241
- category:
- insulated deep groove ball bearing
| name | 61952ma/c3vl0241 | ||
|---|---|---|---|
| new model | 61952ma/c3vl0241 | old model | 61952ma/c3vl0241 |
| inner d | 260mm | outer d | 360mm |
| thick(mm) | 46mm | weight | 13.7kg |
| bearing code number | 61952ma.c3.vl0241 |
| bearing type | deep groove ball bearing |
| insulated type | inner ring or outer ring |
| demensions | 260x360x46mm |
| d | 260mm |
| d | 360mm |
| b | 46mm |
| service | neutral/oem/as your request |
| package | carton boxes /wooden cases /pallets |
| stock qty | 18pcs |
dear purchasing manager, it is my great pleasure to inform you that we still have 18pcs of
61952ma.c3.vl0241 bearing in stock at the moment. please feel free to contact us through email
or skype if you have request for 61952ma.c3.vl0241 bearings and we will spare no efforts to
satisfy your requirements by rendering you the superior quality, the most competitive prices,
premium service and any other specific need.
| nine star insulated bearings detail information |
| vl0241: breakdown voltage 1000v dc, electrical resistance>50mω, outer ring coated |
| vl2071: breakdown voltage 1000v dc, electrical resistance>50mω, inner ring coated |
| vl0244: breakdown voltage 2000v dc, electrical resistance>150mω, outer ring coated |
| vl2074: breakdown voltage 2000v dc, electrical resistance>150mω, inner ring coated |
| vl0246: breakdown voltage 3000v dc, electrical resistance>150mω, outer ring coated |
| vl2076: breakdown voltage 3000v dc, electrical resistance>150mω, inner ring coated |
| commonly used deep groove ball bearing (insulated bearing) |
| 6312m/c3vl0241 6313m/c3vl0241 6314m/c3vl0241 6315m/c3vl0241 6316m/c3vl0241 6317m/c3vl0241 6318m/c3vl0241 6319m/c3vl0241 6320m/c3vl0241 6322m/c3vl0241 6326m/c3vl0241 6328m/c3vl0241 |
| commonly used tapered roller bearing (insulated bearing) |
| 30316/c3vl0241 30317/c3vl0241 30318/c3vl0241 30319/c3vl0241 30320/c3vl0241 30322/c3vl0241 30324 /c3vl0241 30326/c3vl0241 30328/c3vl0241 30330/c3vl0241 32024/c3vl0241 32928/c3vl0241 |
| commonly used cylindrical roller bearing (insulated bearing) |
| nu312ecm/c3vl0241 nu313ecm/c3vl0241 nu314ecm/c3vl0241 nu315ecm/c3vl0241 nu316ecm/c3vl0241 nu317ecm/c3vl0241 nu318ecm/c3vl0241 nu319ecm/c3vl0241 nu320ecm/c3vl0241 nu322ecm/c3vl0241 nu326ecm/c3vl0241 nu328ecm/c3vl0241 |
| commonly used spherical roller bearing (insulated bearing) |
| 22216 ca/w33vl0241 22218 ca/w33vl0241 24152 cc/w33vl0241 23144 cc/w33vl0241 22224 cak/w33vl0241 23130 cc/w33vl0241 23130 cck/w33vl0241 23044 cck/w33vl0241 22224 mb/w33vl0241 |
